90 Ton X 12' Cincinnati Model 90CB Hydraulic Press Brake


Pre Owned Cincinnati Model 90CB Hydraulic Press Brake
Serial Number 46378                New 1989

GENERAL SPECIFICATIONS
Capacity                         90 TONS
Overall Length of Bed & Ram                12’
Distance Between Housings    `            8’6 3/4”
Stroke                            8”
Open Height                        15”
Closed Height                        7”
Throat Clearance                    7”
Speeds
Approach                    260 Inch Per Minute
Form                        10-20-80 Inch Per Minute
Return                        280 Inch Per Minute
Width at Top of Bed                    3 ½”
Main Motor Horsepower                15

EQUIPPED WITH
Variable Tonnage
Narrow Filler Block
Electric Foot Switch
Manuals
Interlocked Construction
Clevis Mounted Self Aligning Cylinders

Approximate Overall Weight                 19500 Lbs
Approximate Overall Dimensions             12’6.5” L X 50”FB X 110” H
